Product Description:
The PR1000LCDRT2U has both a Pure Sinewave
waveform and Full Automatic Voltage Regulation (AVR) technology, which
delivers a consistent and clean AC signal that protects connected
equipment and prevents costly business interruptions. The multifunction
LCD readout provides ready access to power/battery condition vitals,
such as: Runtime, Load, Temperature, and much more.It includes eight
(8) widely spaced, battery and surge protected NEMA 5-15R output
receptacles, including four (4) that are designed to serve as fail-safe
options for protecting critical loads. It also comes with four
maintenance-free, user-replaceable 12V/7Ah batteries. Bundled
PowerPanel® Business Edition Management Software monitors UPS
status
and can provide unattended shutdown of two serially connected servers.
The patented GreenPower UPS advanced circuitry reduces UPS energy costs
by up to 75% compared to competitive models.An optional SNMP / HTTP
Remote Management adapter (RMCARD201) supports remote management and
control of the PR1000LCDRT2U through a standard web browser. The unit
also has a unique convertible design that allows for use in either a
Tower (T) or Rackmount (RM) form factor.Backed by US-based Technical
Support, an industry-leading 3-Year Warranty and a Connected Equipment
Guarantee of $200,000.
|
Plug/Connector Type:
|
NEMA 5-15P
|
|
Receptacles:
|
8 x NEMA 5-15R -
Backup/Surge-protected |
|
Switching Time:
|
4 ms |
|
Dataline Protection:
|
RJ-45 Network
Type F Connector Coaxial Cable Line
|
|
Protection Type:
|
Black Out
AC Surge
EMI / RFI
Overload
Sags
|
|
Load Capacity:
|
1000VA/700W
|
|
Input Voltage:
|
110V AC |
|
Input Voltage Range:
|
80V AC to 150V AC
|
|
Output Voltage:
|
120V AC |
|
Frequency:
|
50 to 60Hz Output
|
|
Voltage Handling:
|
±5%
|
|
Waveform Type:
|
Sine Wave |
|
Surge Energy Rating:
|
1780J |
|
Filtering:
|
EMI/RFI |
|
Circuit Breaker:
|
3 x 15A |
|
Network Management:
|
SNMP Manageable
Optional |
|
Overload Protection:
|
On Battery: Internal Current Limiting
On Utility: Circuit Breaker
|
|
Alarm:
|
Battery Low
On Battery
Overload
|
|
Bypass Switch:
|
Not Provided
|
|
Emergency Power OFF:
|
Yes |
|
Status Indicators:
|
On UnitPower On
Wiring Fault
Multi-function LCD Toggle Panel:Current/Load
Level
Runtime
Battery Level
Temperature (F & C)
Battery In Use
Input Voltage
Output Voltage
Output Frequency
Overload
Wiring Fault
Silent Mode
Normal Mode
|
|
Interfaces/Ports:
|
1 x USB
2 x DB-9 Serial
|
|
Batteries:
|
4 x Maintenance
Free Sealed Lead-acid User-replaceable |
|
Backup/Run Time:
|
11 Minute 700W Full-load
32 Minute 350W Half-load
|
|
Battery Life:
|
3 Year to 6 Year
|
|
Battery Recharge Time:
|
8 Hour Typical
|
|
Temperature:
|
32 °F (0 °C) to 95 °F (35 °C)
Operating
5 °F (-15 °C) to 113 °F
(45 °C) Non-operating
|
|
Humidity:
|
0 to 95% Non-condensing
0 to 95% Absolute Humidity
|
|
Altitude:
|
0 ft to 10000 ft
Operating |
|
Color:
|
Black |
|
Form Factor:
|
2U Rack-mountable
Rack-mountable |
|
Power Cord/Cable:
|
10 ft |
|
Dimensions:
|
3.5" Height x
17.25" Width x 15.75" Depth - Actual Unit |
|
Shipping Dimensions :
|
20in Width x 21in
Depth x 10.5in Height - Display Box |
|
Case Pack Qty :
|
1 |
|
Pallet Qty :
|
99999 |
|
Package Contents:
|
UPS Unit
Rack Ears (2)
Stands/Legs (2)
User Manual
Power Management Software
Warranty Card
Serial Cable
EPO Cable
USB Cable
|
|
Additional Information:
|
Pure
Sinewave – This UPS generates pure sinewave energy that is identical
to, or cleaner than the utility company’s power grid. Benefits include:
low total harmonic distortion, minimal electrical noise, and optimal
line clarity.
Microprocessor-based
Digital Control – Digital routing is maintained through a network of
integrated circuitry and discrete values are used for internal system
processing, which significantly increases efficiency and response of
CyberPower UPS’s.
RM/T Configuration – The PR series can
be configured in either a Tower or a Rackmount (2U) form.
Full
AVR – Boost/Buck – Boost/Buck topology will both increase low voltages
and decrease high voltages, without switching to battery-mode. This
conserves battery life, and delivers a more stable signal to your
connected equipment.
Energy-Saving
Technology - The patented GreenPower UPS™ advanced circuitry
reduces
UPS energy costs by up to 75% compared to competitive models.
Dual PC Support – The unit has 2 (two)
communication ports that allow the user full control of dual PCs or
servers.
Critical
Load Outlets - Prioritize the uptime of mission-critical loads during a
power failure with critical load outlets that ensure power to selected
systems during an extended blackout, preserving battery uptime for more
critical equipment.
EMI/RFI - Provides
shielding against electromagnetic interference & radio frequency
signals. Most commonly, this is used to prevent line noise or “humming”
that occurs over telephone lines or stereo electronics.
PowerPanel
Business Edition Software – In the event of a power outage, PowerPanel
will safely save and close your open files and shut your computer down
in an orderly, intelligent manner. The software allows users to view
detailed information about their electrical power and the vitals of the
UPS. It includes configurable system notifications, automatic self
tests, adjustable high/low voltage warnings, event/data logging, and
scheduled shutdowns.
Metal Housing – Rigid metal
construction allows for placement in areas with a demanding environment.
Multifunction
LCD readout - The multifunction LCD readout provides ready access to
power/battery condition vitals, such as: Runtime, Load, Temperature,
and much more.
Audible Alarms - Audible tones
identify when the unit is running off battery power, unit overloads,
and low battery.
Resettable Circuit Breaker -
Convenient unit reset switch in case of an overload.
3-year
Warranty - CyberPower will replace damaged units if within 3 years of
purchase date. We stand behind our products and guarantee quality.
CyberPower also offers a #1 rated technical support team that will
assist you with product, installation, or warranty concerns --- Free of
Charge!
ISO & Safety Certifications
- All CyberPower manufacturing facilities are ISO-9001 Quality Tested.
Our products are also certified by the FCC, cUL, and UL.
Windows
compatibility - Our power management software has been fully tested and
is compatible with Windows 2000, Server 2003, XP 32/64, Vista 32/64,
and Server 2008
|
|
Certifications & Standards:
|
FCC Class B certified
cUL
UL 1778
|
|
Software Included:
|
PowerPanel
Business Edition Software |
|
Green Compliance:
|
Yes |
|
Country of Origin:
|
China |
|
Standard Warranty:
|
3 Year Parts
& Labor/Replacement |
|
Parts Warranty/Labor:
|
3 Year Parts
& Labour |
|
Additional Warranty Information:
|
CyberPower
stands behind its products by offering an industry leading 3-year
warranty. CyberPower also has a #1 rated technical support team that
will assist you with product, installation, or warranty concerns ---
Free of charge. |
|
