Product Description:
Sony's VPL-E Series data projectors are extremely affordable and ideal
for a number of applications, especially in education and business.
Sony's VPL-EW5 is not only stylish, but also provides a high brightness
of 2000 lumens. If widescreen projection is desired, the VPL-EW5 offers
WXGA resolution. This projector comes equipped with a short
focal-length lens enabling large-screen projection from a very short
distance. Because this projector was designed primarily for education
and business, it is very easy to use and provides security features
such as a password authentication system and a security bar. In
addition, it offers a variety of interfaces such as a monitor output,
audio output, RS-232C for control, and High-Definition Multimedia
Interface (HDMI) for digital video projection. All of these features
combine to make the VPL-E Series ideal for both classrooms and
conference rooms.
| Device Type |
LCD projector - High Definition 720p |
| Built-in Devices |
Speaker |
| Width |
12.4 in |
| Depth |
10.6 in |
| Height |
4.3 in |
| Projector / Panel |
| Image Brightness |
2000 ANSI lumens |
| Image Brightness
(Reduced) |
1600 ANSI lumens |
| Image Contrast
Ratio |
700:1 |
| Image Size |
3.3 ft - 25 ft |
| Resolution |
1280 x 800 |
| Native Aspect
Ratio |
Widescreen |
| Display Format |
3,072,000 pixels (1,280 x 800 x 3) |
| Max Sync Rate (V
x H) |
92 Hz x 92 kHz |
| Lamp Type |
UHP 190 Watt |
| Lamp Life Cycle |
2000 hour(s) / 3000 hour(s)
(economic mode) |
| Projector Lens System |
| Focus Type |
Manual |
| Lens Aperture |
F/1.65-1.93 |
| Zoom Type |
Manual |
| Zoom Factor |
1.2x |
| Keystone
Correction Type |
Digital |
| Keystone
Correction Direction |
Vertical |
| Vertical
Keystone Correction |
-30 / +30 |
| Video Input |
| Analog Video
Format |
NTSC, SECAM, PAL, PAL-N, PAL-M, NTSC
4.43, PAL 60, NTSC 3.58 |
| Analog Video
Signal |
RGB, S-Video, composite video,
component video |
| Digital
Television Video Formats |
480p, 720p, 1080i, 480i, 575i, 575p |
| Video Output |
| Analog Video
Signal |
RGB, component video |
| Audio Output |
| Type |
Speaker(s) - integrated |
| Sound Output Mode |
Mono |
| Output Power /
Channel |
1 Watt |
| Speaker(s) |
1 x mixed channel |
| Input Device |
| Type |
Remote control - external - wireless |
| Expansion / Connectivity |
| Interfaces |
1 x S-video input - 4 pin mini-DIN
1 x composite video input - RCA
2 x audio line-in - mini-phone stereo 3.5 mm
1 x component video / RGB input - 15 pin HD D-Sub (HD-15)
1 x HDMI input - 19 pin HDMI Type A
1 x component video / RGB output - 15 pin HD D-Sub (HD-15)
1 x audio line-out - mini-phone stereo 3.5 mm
1 x serial RS-232C - 9 pin D-Sub (DB-9) |
| Miscellaneous |
| Included
Accessories |
Carrying case, lens cover |
| Cables Included |
1 x VGA cable - 6 ft |
| Compliant
Standards |
FCC Class B certified, CE, IC Class
B, C-Tick, cUL, FIMKO, NOM, SASO, CSA 22.2 No. 60950, CCC, EMC, PSB, UL
60950-1, EN 60950-1 |
| Power |
| Power Device |
Power supply - internal |
| Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
| Power
Consumption Operational |
260 Watt |
| Environmental Parameters |
| Min Operating
Temperature |
32 °F |
| Max Operating
Temperature |
95 °F |
| Humidity Range
Operating |
35 - 85% |
| Sound Emission |
39 dB |
| Sound Emission
(Economic Mode) |
33 dB |
|
