DIGI
Digi Passport 48 Integrated Console Server w/ freeKVM, dual power & internal modem (48 RJ-45 serial ports)


1308882_DIGI_INTERNATIONAL_70002286.jpg-
Manufacturer DIGI
Mfg. Part # 70002286
ITEM# 775367
Unit Price $10,109.04 (~CAD$12,600.92)
Availability It may take 2-3 weeks to ship out. In Stock
Buy


Shipping and Handling:
 INTERNATIONAL GROUND SHIPPING:
For qualified orders, we will waive the Brokerage/Handling Fee for Custom Clearance and Documentation

No other hidden fees will be collected from you when packages arrive. Guaranteed
[ Detailed Explanation ]
[ View Detail Product Info ]


Product Description:
The latest entry in Digi's console management line, the Digi Passport provides secure remote access to the console ports of computer systems and network equipment over Ethernet or dial-up connections. Offering native support for the Intelligent Platform Management Interface (IPMI), the Digi Passport can communicate with virtually any server or device. With freeKVM, the Digi Passport also provides network-based graphical access to servers, providing a single interface through which to remotely administer systems and run desktop applications without the cost and complexity of traditional KVM over IP solutions.

Device Type Console server
Width 17.4 in
Depth 10 in
Height 1.7 in
Networking
Form Factor External
Ports Qty 48
Connectivity Technology Wired
Data Link Protocol RS-232
Routing Protocol RIP
Remote Management Protocol Telnet, SNMP 3, HTTP, HTTPS, IPMI 2.0
Features Auto-sensing per device, Syslog support, manageable, IPv6 support, IP address filtering, firmware upgradable, RealPort technology
Encryption Algorithm SSL
Authentication Method Kerberos, RADIUS, TACACS+, Secure Shell v.2 (SSH2), LDAP
Compliant Standards USB 2.0
Communications
Type Modem (analog) - integrated
Expansion / Connectivity
Expansion Slots Total (Free) 1 ( 1 ) x PC Card
Interfaces 48 x serial - RS-232 - RJ-45
1 x management - console - RJ-45
2 x network - Ethernet 10Base-T/100Base-TX - RJ-45
1 x Hi-Speed USB - 4 pin USB Type A
1 x modem
Miscellaneous
Rack Mounting Kit Included
Compliant Standards FCC Class A certified, EN55022, UL 1950, EN55024, FCC Part 15, RoHS
Power
Power Device Power supply - redundant - internal
Installed Qty 2
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational 40 Watt
Power Provided 15 Watt
Manufacturer Warranty
Service & Support 5 years warranty
Service & Support Details Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature 41 °F
Max Operating Temperature 122 °F
