MODEL- 5660-00-00AF       VENDOR- ZOOM TELEPHONICS

FEATURES- X3 Ethernet ADSL 2/2+ Modem
       External ADSL Modem/Router/Gateway with Ethernet Interface.
       The Zoom ADSL X3 Gateway, Model 5660, is a full-rate ADSL 2/2+ modem
        and a powerful gateway/router in a single affordable product.
       The Zoom Model 5660 delivers up to 24 Mbps data speeds over existing
        telephone wires and is suitable for use in homes or small offices.
        The Model 5660 is compatible with older ADSL protocols as well as
        the new ADSL 2/2+ standards for higher data speeds and extended
        distances at which high data rates can be delivered.
       An Ethernet interface on the X3 provides connection to a computer
        running most operating systems, including Windows 95, 98, 98SE,
        2000, XP and Me as well as Linux, Unix and Mac Operating system.
        The X3 can also be plugged into a hub or wireless access point to
        provide concurrent Internet access for up to 253 networked
        computers.
       Security features include Network Address Translation (NAT), and
        Stateful Packet Inspection (SPI). The NAT firewall hides computers
        on the local area network from uninvited access through the
        Internet. SPI assesses the protocol and packet addresses being
        received to determine if the information should be passed through
        the firewall to the connected computers. SPI and NAT protect
        against Internet worms and Denial of Service attacks, some of the
        most publicized forms of malicious intrusion from the Internet.
       Setup is easy using any authorized local or remote computers Web
        browser and the intuitive graphical user interface. An auto
        configuration option automatically establishes the protocol and
        encapsulation used by the ADSL service. Simple Network Management
        Protocol (SNMP) is supported for remote maintenance by network
        administrators.
       Zoom ADSL gateways are backed by a two year warranty and over 27
        years of experience in the design and support of communication
        products.
    Includes ADSL Gateway, Ethernet cable, Phone cable, CD-ROM, User
      manual, Power adapter, Filters and phone adapters.
* ADSL 2/2+ compliant for faster ADSL speeds and extended distances at
  which high-speed data can be delivered.
* High-speed "always-on" Internet access
* ADSL modem plus router supports up to 253 concurrent Internet users.
* Advanced security from hacker attacks with Stateful Packet Inspection
  (SPI) and Network Address Translation (NAT) firewalls.
* Works with all popular ADSL services
* Fast and easy installation with auto configuration
* Two phone jacks, including one filtered jack to support an attached
  telephone.
* Software upgradeable
* Ethernet interface for use with most operating systems
* Works great with wireless access points
* SNMP support (Simple Network Management Protocol)
* Documentation and software provided in Danish, Dutch, English, French,
  Portuguese, and Spanish.

  -- SPECIFICATIONs ---------------------------------
ADSL COMPLIANCE-
               Compliant with ADSL standards:
                  - Full-rate ANSI T1.413 Issue 2, ITU G.dmt (G.992.1)
                    standards.
                  - Splitterless G.lite (G.992.2) specification
                  - Annex A
               Compliant with ADSL 2 standards:
                  - ITU G.992.3
                  - ADSL Annex L (reach extended DSL)
               Compliant with ADSL 2+ standards:
                  - G.992.5
               DMT modulation and demodulation
               Full-rate adaptive modem
                  - Maximum downstream rate of 24 Mbps
                  - Maximum upstream rate of 1024 Kbps
               Supports splitterless ADSL implementation
               Interoperable with all major DSLAM manufacturers
ATM PROTOCOLS- WAN mode support: PPP over ATM (RFC 2364) and PPP over
                                  Ethernet (RFC 2516)
               LAN mode support: bridged/routed Ethernet over ATM (RFC
                                  1483) and Classical IP over ATM (RFC
                                  1577)
               ATM Forum UNI 3.1/4.0 PVC
               Up to eight virtual circuits
               ATM segmentation and re-assembly
               ATM AAL5 (adaption layer type 5)
               OAM F4/F5
BRIDGE MODE  - Ethernet to ADSL self learning - Transparent Bridging (IEEE
                 802.1D).
               Supports up to 128 MAC learning addresses
ROUTER MODE  - Static routing
               DNS Proxy
               IP filtering
               DHCP (Dynamic Host Configuration Protocol) server and client
                 and Relay.
               NAT (Network Address Translation)
               NAPT (Network Address and Port Translation)
               RIP V1 and V2
               PPP Half Bridge
               Dynamic DNS
               Virtual Server/DMZ Support
SECURITY     - Network Address Translation
               SPI (Stateful Packet Inspection)
               Denial of Service Protection
               Attack Protection
               Service Filtering
               Virtual Private Networking Pass Through
               Software and Games Port Control
               User authentication for PPP
               PAP (Password Authentication Protocol)
               CHAP (Challenge Authentication Protocol)
               Password Protected System Management
               Blacklists
               Protocol Blocking
               Bridge Filtering
MANAGEMENT   - Password security
               SNMP Version 2.0
               Universal Plug and Play (UPnP)
               Remote and local command line or HTTP interface
                 configuration.
               Software upgradeable firmware through HTTP interface
               ATM traffic management functions support UBR, CBR, rt-VBR,
                 nrt-VBR in accordance with ATM forum 4.1.
               Loads setup from a file for easy input of a service
                 providers configuration.
CONNECTORS   - Ethernet: IEEE 802.3 compliant
                         (4) 10/100 BaseT auto-sensing RJ45 ports
               Phone   : (2) RJ-11 jacks, one for the ADSL/PSTN connection
                         (1) Filtered jack for local phones
WEB-BASED    - HTTP Graphical User Interface
               Password protected access
               Firmware upgrades
               WAN and LAN side connection statistics
               Configuration of static routes and routing table
               Configuration of NAT/NAPT
               Selection of bridge or router mode
               PPP user ID and password
               Configuration of virtual circuits
INDICATORs   - LEDs for Link, LAN activity, Power
APPROVALS    - CE, UL, C-UL, FCC Part 15B, FCC Part 68, CS-03
REQUIREMENTS - A computer with an Ethernet port and any operating system
                 that supports TCP/IP (Windows, Mac, Linux or other).
DIMENSIONS   - 5.7" x 4.4" x 1.1"
