Product Description:
IOGEAR's eight-port Miniview Ultra+ KVM switch is the ideal tool to
help reduce redundant hardware. Eight monitors, mice and keyboards are
simply too expensive, bulky and inconvenient for most system
administrators. Why bother when you can control all eight, or even up
to 512 computers with a single keyboard, monitor and mouse. The added
audio support allows you to enjoy music while working. Just think of
the time, space and money you'll save, and added fun. The Miniview
Ultra+ is much more than a simple eight-port KVM switch. The dual
interface support allows you to connect both PS/2 and USB computers on
the same switch. The multi-platform support allows you to control
Windows based computers, Sun Solaris systems, Linux, or even Macs by a
single KVM switch. IOGEAR extended the multi-platform support by
supporting the special keys on both Sun and Mac keyboards. This KVM
switch also comes with the IOGEAR VSE technology, which provides
excellent video resolution - up to 2048 x 1536. Built-in AutoScan mode
lets you conveniently monitor every attached computer for a specified
amount of time, while On Screen Display (OSD) technology allows you to
assign a unique name to each computer and access it via a smooth
menu-driven interface. With its 1U, 19" rack-mountable casing and
status-monitoring LEDs, the Miniview Ultra+ is the perfect switch for
your server room or any other multi-computer environment.
Specifications
| Product Description |
IOGEAR MiniView Ultra+ GCS1758 - KVM / audio switch - 8 ports |
| Device Type |
KVM / audio switch - cascadable |
| Form Factor |
External - 1U |
| Dimensions (WxDxH) |
17 in x 6 in x 1.7 in |
| Ports Qty |
8 |
| KVM Users Qty |
1 local user |
| Features |
On-Screen Display, firmware upgradable |
| System Requirements |
SunSoft Solaris, Apple MacOS, Microsoft Windows |
| Manufacturer Warranty |
3 years warranty |
| General |
| Device Type |
KVM / audio switch - cascadable |
| Enclosure Type |
External - 1U |
| Width |
17 in |
| Depth |
6 in |
| Height |
1.7 in |
| Networking |
| Ports Qty |
8 |
| Connectivity
Technology |
Wired |
| Status Indicators |
Power, select |
| Features |
On-Screen Display, firmware
upgradable |
| KVM |
| KVM Local Users
Qty |
1 local user |
| Max Cascading
Depth |
3 |
| Max Resolution |
2048 x 1536 |
| Expansion / Connectivity |
| Interfaces |
8
x keyboard / video / mouse (KVM) - 15 pin HD D-Sub (HD-15) female
Ý 8 x
audio - line-out - mini-phone stereo 3.5 mm female Ý 8 x
microphone -
input - mini-phone 3.5 mm female Ý 1 x management - RJ-11 female |
| Connections |
1
x display / video - VGA - 15 pin HD D-Sub (HD-15) female - 1 Ý 1
x
audio - line-out - mini-phone stereo 3.5 mm female - 1 Ý 1 x
microphone
- input - mini-phone 3.5 mm female - 1 Ý 1 x keyboard - 4 pin
USB Type
A female - 1 Ý 1 x mouse - 4 pin USB Type A female - 1 |
| Miscellaneous |
| Cables Included |
4 x keyboard / mouse / video / audio
cable - 10 ft Ý 4 x keyboard / mouse / video / audio cable - 6
ft Ý 1 x data cable |
| Rack Mounting Kit |
Included |
| Compliant
Standards |
FCC Class B certified, DDC-2B, RoHS |
| Power |
| Power Device |
Power adapter - external |
| Software / System Requirements |
| OS Required |
SunSoft Solaris, Apple MacOS,
Microsoft Windows |
| Manufacturer Warranty |
| Service &
Support |
3 years warranty |
| Service &
Support Details |
Limited warranty - 3 years |
|
