MODEL- SLM2008            VENDOR- LINKSYS

FEATURES- 8-Port Business series Smart Gigabit Ethernet Switch
       8-port 10/100/1000 Gigabit Smart Switch with PD and AC power!
       Cost-effective Gigabit switching with entry-level management for
        small business.
       Linksys Business Series Smart Gigabit Ethernet Switches deliver
        cost-effective switching solutions that are ideal for small
        businesses or workgroups within larger organizations. These high-
        speed switches offer entry-level management without the cost and
        complexity of a full Layer 2 managed switch.
       The SLM2008 switch is ideal for conference rooms, labs,
        shipping/receiving departments or in marketing, design or
        audio/visual workgroups. The eight 10/100/1000 Mbps (Gigabit
        Ethernet) ports enable companies to link to other Gigabit devices
        on the network (servers, workstations and network storage) to
        quickly move bandwidth-intensive files while still supporting
        10/100 Mbps clients.
       The SLM2008 supports the IEEE802.3af standard for Power over
        Ethernet (PoE) for obtaining its power over a designated PD port or
        from an external AC power adapter. This gives companies the option
        to install the switch in places where a power outlet may not be
        present, such as in ceilings and in walls.
       The SLM2008 is able to secure the network through IEEE 802.1Q VLANs
        and IEEE 802.1X port authentication. For environments where IP
        multicast applications are used, the switch is capable of limiting
        the traffic to only the ports that have requested that traffic with
        support of IGMP Snooping. Additional QoS capabilities like IEEE
        802.1p, DSCP, and 4 hardware queues make it possible to maintain
        good quality for real-time applications like voice and video.
       The SLM2008 offers an easy-to-use browser interface for the
        management and configuration of the features, making it ideal for
        small businesses without an IT staff or that have minimal technical
        expertise.
    Includes SLM2008 with 8 10/100/1000 Ports, AC Power Adapter with Power
      Cord, CD with User Guide in PDF Format, Online Registration Card.
* 8 Gigabit Ethernet ports ideal for small workgroups moving large files.
* Can obtain power from a standard 802.3af PoE switch or from an external
  AC power outlet.
* Entry-level management at a cost-effective price point.
* Easy to use Web browser interface make installation quick and easy.

  -- SPECIFICATIONs -----------------------------------
CONNECTORs   - (8) 10BaseT/100BaseTX/1000BaseT/RJ-45 ports
               Auto MDI/MDI-X
               Auto-negotiate/Manual setting
BUTTONS      - Reset Button
CABLE TYPE   - UTP CAT 5 or better for 10BASE-T/100BASE-TX, UTP CAT 5e or
                 better for 1000BASE-T.
INDICATORS   - LEDs for Link/Act, System
PoE          - IEEE 802.3af PoE-PD Compatible on Port 1. Supply System
                 Power Without an External Power Adapter.
PERFORMANCE  - Switching Capacity: 16 Gbps, non-blocking
               Forwarding Rate   : 11.9 Mpps Wire-Speed Performance
LAYER 2      - MAC table size    : 8K
               Number of VLANs   : 16 active VLANs (4096 range)
               VLAN              : Port-based and 802.1Q Tag-based VLANs
               HOL Blocking      : Head of line blocking prevention
MANAGEMENT   - Web User Interface: Built-in Web UI for easy browser-based
                                     configuration.
               Firmware Upgrade  : Web Browser upgrade (HTTP)
               Port Mirroring    : Traffic on a port can be mirrored to
                                     another port for analysis with a
                                     network analyzer.
               Other Management  : RADIUS
                                   Port mirroring
                                   DHCP client
                                   PING
SECURITY     - IEEE 802.1x       : 802.1x - RADIUS Authentication.
                                   MD5 Encryption
AVAILABILITY - Link Aggregation  : Link Aggregation using IEEE 802.3ad LACP
                                   Up to 5 ports in up to 2 groups
               Storm Control     : Broadcast and Multicast
               Spanning Tree     : IEEE 802.1D Spanning Tree
               IGMP Snooping     : IGMP (v1/v2) snooping limits bandwidth-
                                     intensive video traffic to only the
                                     requestors. Support 16 multicast
                                     groups.
QoS          - Priority levels   : 4 Hardware queues
               Scheduling        : Priority Queuing and Weighted Round
                                     Robin (WRR).
               Class of Service  : Port-based
                                   802.1p VLAN priority based
                                   IPv4/v6 IP DSCP based
STANDARDS    - 802.3 10BASE-T Ethernet, 802.3u 100BASE-TX Fast Ethernet,
                 802.3ab 1000BASE-T Gigabit Ethernet, 802.3z Gigabit
                 Ethernet, 802.3x Flow Control, 802.3 ad LACP, 802.3af PoE,
                 802.1D STP, 802.1Q/p VLAN, 802.1X Port Access
                 Authentication.
REQUIREMENTS - Web-Based Utility: Web Browser-Microsoft Internet Explorer
                 (Version 6.0 or Above), Firefox (Version 2.0.0.1 or
                 Above).
               CAT5 Ethernet Network Cable
               Switch/Router with Power Over Ethernet (PoE) Support Or PoE
                 Injector when used with PoE.
               Operating System: Windows, XP or Above
APPROVALS    - FCC Part15 Class B, CE Class A, UL, cUL, CE mark, CB
POWER SOURCE - External AC Power Adapter, and IEEE 802.3af Compatible
                 PoE-PD.
DIMENSIONS   - 5.12"w x 1.12"h x 5.12"d       WT.- 0.91 lbs.
