Features :

- ATX12V Ver 2.2

Full compliance with the highest standard to desktop power supply design requirements recommended by Intel. Split 12V rails provide most stable current to CPU, GPU , MB and drives.

- ATX/ BTX/CEB/EEB

Convertible design to power ATX/BTX system and support Dual CPU entry-level server/workstation.

- Silent 120mm fan

Special design 12cm fan combines silence and cooling by intelligent speed control.

- Modular Cables

Smart modular cable management to optimize maximum air flow.

- Eternity Connectors

Unique 4-pin Molex + SATA connectors in pairs give you free choice on using either PATA or SATA devices.

- PCI Express x 2

Support Dual Graphic card setup (Sli or Crossfire)

- High Efficiency (80%)

High efficiency is achieve by using using high quality components and the skills of our designer to maximizes your power supply output and minimize wasted power. Efficiency is the measure of how much of the 100% power going in to the PSU is being used up and the unused power dissipate into heat through the heatsink. Lower efficiency means that more power is being wasted and also the PSU will generate more heat. .

- Maximum Shielding

Toughest EMI shielding protects your system and near-by appliances.

- Protection

Enermax has one of the highest protection standard on the market today, due to our advance design we offer the following type of protections:

OCP -Over Current Protection, UCP -Under Current Protection, OVP - Over Voltage Protection, OLP -Over Load Protection, OTP - Over Temperature Protection, SCP - Short Circuits Protection.

Specifications :
Power: 400W (support both 20pins and 24pins DUAL CPU motherboards)
Efficiency: 80%
Active PFC: Yes
Input Voltage: 90V~265V (Auto Adjusted)
Input Frequency Range: 47Hz~63Hz
Input Current: 40A/115V and 80A/230V max. during cold start
Hold up time: 17ms at 115VAC or 230VAC, full load
Over Voltage Protection: +5V: 5.5V~7.0V; +3.3V:3.76V~4.3V; +12V & +12V2: 13.4V~15.6V
Over Load Protection: 110~160% of max load
Over current Protection: +3.3V : 55A (max); +5V: 48A (max); +12V1 & +12V2: 20A (max)
Over Temperature Protection: Operating Ambient 10ºC~40ºC, Storage Ambient -40ºC~70ºC
Humidity:
Operating : to 85% relative humidity, non condensing at 25ºC
Storage: to 95% relative humidity, non condensing at 50ºC
MTBF: Greater than 100K hours at 70% of full rated load; 230VAC / 50Hz input; 25ºC ambient
EMC: EN55022 Class B, EN61000-4-2 Class B, EN61000-4-3 Class A, EN61000-4-4 Class B, EN61000-4-5 Class B, EN61000-4-6 Class A, EN61000-4-8 Class A, EN61000-4-11 Class B, FCC Part 15 & Part 2, CNS 13438 Class B
Safety: Approval UL, cUL, TÜV, CB
Dimension: W150 x H86 x D140 (mm)
