MODEL- NN-PC8312-S2       VENDOR- SIIG

FEATURES- FireWire 800 Cardbus DV Kit
       FireWire 800 3-port (1394b x 2, 1394a x 1) CardBus PC card with
        deluxe DV editing software and FireWire DV cable. RoHS compliant.
       Upgrades your notebook and PC computer with the latest FireWire 800
        interface for multiple device connections.
    Includes FireWire 800 3-port (2b+1a) CardBus Card, 1394a 6-pin to 4-pin
      DV cable (3 ft), Ulead VideoStudio 7.0 SE DVD software, Driver
      software and User s manual.
* Provides two 1394b and one 1394a (6-pin) ports.
* Supports serial bus data transfer rates up to 800Mbps.
* Supports both isochronous and asynchronous data transfer modes.
* Hot-swapping, dynamic reconfiguring of up to 63 devices on the bus; no
  need to turn off the system while adding or removing 1394 devices.
* Works with various types of FireWire 800 (1394b) and 1394a devices
  including portable hard disks, DV camcorders (Sony, Panasonic, Canon,
  Sharp, JVC and others), CD-RW/DVD-ROM drives, digital cameras, and other
  audio/video devices.
* Supports IEEE P1394b and backwards compatible with 1394a-2000 and
  1394-1995 standards.
* Fully interoperable with FireWire, iLINK and SB1394 implementation of
  IEEE 1394 standards.
* Supports data transfer rates of 100, 200, 400 and 800Mbps
* Supports both isochronous and asynchronous data transfer modes.
* A 1394a cable (6-pin to 4-pin) is included

  -- SPECIFICATIONs ----------------------------------
INTERFACE/BUS- 32-bit PCMCIA CardBus interface with Power Management
CONNECTORs   - (2) IEEE-1394b/Firewire 800 ports (9-pin)
               (1) IEEE-1394a/Firewire 400 port  (6-pin)
CHIPSET      - TI TSB81BA3 (PHY) & TSB82AA2 (LYNX)
REQUIREMENTS - Pentium-class (300MHz) portable computer
               available CardBus Type II slot
               Windows 98SE/ME/2000/XP or later
               Recommended system for digital video creating/editing:
                 - Pentium III or above PC computer
                 - 128MB RAM and CD-ROM drive
                 - 4 GB of available hard disk space
                 - Video card with 4MB RAM
                 - Windows 98SE or later
APPROVALS    - FCC Class B & CE
