MODEL- WG50553            VENDOR- WATCHGUARD

FEATURES- Firebox X550 Core e-series Firewall UTM Bundle
       This UTM bundle includes Firebox X Core 550e, One year of Security
        Service subscriptions for GAV/IPS, spamBlocker, and WebBlocker as
        well as the LiveSecurity Services.
       Our Firebox X Core e-Series Unified Threat Management (UTM)
        solutions provide the most complete security in their class,
        integrating built-in Zero Day protection with multiple security
        features for an unbeatable combination of security capabilities.
       Powerful, yet easy to configure and manage, they protect your
        network with multi-layered defenses to block viruses, worms,
        trojans, spyware, spam, DoS and DDoS attacks, SQL injections,
        buffer overflows, Web-based exploits, and other blended threats.
       The X550e is the most economical of the Firebox X Core models. With
        up to 125 Mbps firewall throughput, it comes equipped with one
        Branch Office VPN tunnel (upgradeable to 10), and five Mobile User
        VPN tunnels (upgradeable to 10). Includes four 10/100 ports. An
        excellent choice for a stand-alone office or small branch office.
* Every Firebox X Core e-series model integrates:
   - Dynamic stateful packet firewall
   - Virtual Private Networking (VPN)
   - Intelligent Layered Security (ILS)
   - Zero Day attack prevention
   - Gateway antivirus (optional)
   - Intrusion prevention (optional)
   - Anti-spyware (optional)
   - Anti-spam (optional)
   - URL filtering (optional)
   - Fireware Pro advanced operating system (optional)
   - Managed desktop antivirus protection
   - WatchGuard System Manager (WSM)
   - 90-day renewable LiveSecurity Service subscription
* Unified Threat Management
   Firebox X Core integrates a powerful combination of stateful packet
   firewall, VPN, zero day attack prevention, gateway antivirus, intrusion
   prevention, anti-spyware, URL filtering, and spam blocking into a single
   appliance, reducing the time and cost associated with managing multiple-
   point solutions.
* Advanced OS
   WatchGuard Firebox System (WFS) ships standard on the Firebox X Core.
   More complex network environments may want to upgrade to the Fireware
   Pro advanced operating system for:
    - Greater control
      Granular control of attachments coming into the network provides the
      ability to allow file types and location by URL, so threats are
      stopped while key operations are not interrupted.
    - Multi-WAN load sharing and interface failover
      Allows up to four ISP connections to distribute traffic and provide
      failover, increasing performance and uptime.
    - Traffic management and prioritization
      Ensures that business-critical applications get the bandwidth they
      need.
    - Port independence
      Any port can be configured as External, Optional (DMZ), or Internal
      (Trusted).
    - High availability (Active/Passive)
      Offers redundancy to a standby appliance
    - Dynamic routing (BGP, OSPF, RIP)
      Maximizes network flexibility, redundancy, and efficiency by
      dynamically updating routing tables.
* Intelligent Layered Security
   - Powerful, proactive protection
     Scans traffic to identify and block malicious threats including
     viruses, worms, spyware, trojans, spam, and blended threats.
   - Zero day protection
     Anything that does not conform to standard Internet protocols,
     behaviors, and patterns is identified and stopped, keeping you
     protected from emerging threats during the window of vulnerability
     when signatures are not yet available.
   - Optimized for better performance
     Keeps data flowing smoothly and efficiently through the network using
     cooperative communication between multiple security layers.
   - Blocks attack sources
     Hosts exhibiting suspicious behavior, such as port scans and Denial of
     Service attacks, are identified and added to the blocked sites list.
     Future traffic from these sources is automatically blocked.
   - Cloaks the network
     Hides your network services from hackers scanning for exploitation
     opportunities.
* Intuitive User Experience with WatchGuard System Manager 8.x
   - Smart defaults
     Pre-defined smart defaults in WatchGuard System Manager mean that your
     security is ensured from the moment you turn on your Firebox.
   - Tools to make customization easy
     Easily configure Firebox X Core to meet your specific business needs
     with features such as drag-and-drop VPN creation, intuitive wizards,
     and flexible security policies.
   - Interactive real-time monitoring and comprehensive reporting
     You will know what is happening in your security system at all times
     and can take immediate preventive or corrective action.
* Security Services
   Expand and extend protection with security services, including:
    - Gateway AntiVirus/Intrusion Prevention Service with anti-spyware
      Provides robust protection against e-mail-borne threats, spyware,
      Web-based exploits, and blended threats. Controls IM and P2P usage.
    - WebBlocker URL filtering
      Blocks malicious Web sites, protecting organizations from increased
      legal liability, lost productivity, and bandwidth depletion.
    - spamBlocker
      The industrys best at distinguishing legitimate communications from
      spam attacks in real time, blocking up to 97% of unwanted e-mail.
* Model Upgradeability and Expandability
   - Upgradeable
     Upgrade to any higher model within the line with a simple license key
     as your performance requirements increase.
   - Expandable
     Use license keys to easily add features and capabilities as needed,
     including Gateway AntiVirus for E-mail and URL filtering.
   - Advanced OS
     Upgrade to Fireware Pro, our advanced operating system for more
     demanding networks.
* Expert Guidance and Support
   Firebox X Core is backed by our LiveSecurity Service, the most
   comprehensive support and maintenance offering in the industry,
   providing: Up-to-the-minute security warnings
              Software updates
              Technical support
              Advance hardware replacement
              Training, tutorials, and self-help resources

  -- SPECIFICATIONs -----------------------------------
INTERFACES   - 10/100             : 4
               10/100/1000        : 0
               Serial Port        : 1
               Security zones     : 4
PERFORMANCE  - Firewall Throughput: 125 Mbps
               VPN Throughput     : 20 Mbps
               Concurrent Sessions: 25,000
               Nodes supported    : Unlimited (LAN IPs)
VPN          - Branch Office VPN
                           tunnels: 1/10 (included/max.)
               Mobile User VPN
                           tunnels: 10
               Mobile User VPN
                   Client Licenses: 5
               Encryption (DES, 3DES, AES 128-, 192-, 256-bit)
               IPSec
               Point-to-Point Tunneling Protocol (PPTP) Server and
                 Passthrough.
               Dead Peer Detection (RFC 3706)
               Hardware-based Encryption
SECURITY     - Stateful Packet Firewall
               Deep Application Inspection Firewall
               Application Proxies - HTTP, SMTP, FTP, DNS, TCP
               DoS and DDoS Prevention
               Progressive DDoS Prevention
               Protocol Anomaly Detection
               Behavioral Analysis
               Pattern Matching
               Fragmented Packet Reassembly Protection
               Malformed Packet Protection
               Static Blocked Sources List
               Dynamic Blocked Sources List
               Time-based Rules
USER AUTHENTICATION-
               XAUTH: RADIUS
                      LDAP
                      Windows Active Directory
               RSA SecurID
               Web-based
               Local Authentication
IP ADDRESS ASSIGNMENT-
               Port Independence
               Static
               PPPoE Client
               DHCP Server, DHCP Client, DHCP Relay
               Dynamic DNS Client
REDUNDANCY   - High Availability (Available with Fireware Pro advanced
                 appliance software upgrade).
                   - HA Active/Passive
                   - Configuration Synchronization
                   - Session Synchronization
                   - VPN Tunnel Synchronization
               Multi-WAN Failover
                   - WAN Failover Ports - 4
                   - WAN Failover Modes (Active/Passive)
LOAD SHARING - Round Robin Load Sharing
               Up to 4 Ports
TRAFFIC MANAGEMENT & PRIORITIZATION
               Maximum Bandwidth
               Maximum Connections/Second
               Traffic Prioritization/QoS (Available with Fireware Pro
                 advanced appliance software upgrade).
                  - 2 Prioritization Levels
ROUTING      - Static Routes
               RIPv1, v2
               BGP4
               OSPF
MODES OF OPERATION-
               Transparent/Drop-in Mode (Layer 2)
               Routed Mode (Layer 3)
ADDRESS TRANSLATION-
               Static NAT (Port Translation)
               Dynamic NAT
               One-to-One NAT
               IPSec NAT Traversal
               Policy-based NAT
LOGGING/REPORTING-
               Multi-appliance Log Aggregation
               WebTrends Compatible Reports (WELF)
               HTML Reports
               XML Log Format
               Encrypted Log Channel
               Syslog
               SNMP
ALARMS/NOTIFICATIONS-
               SNMP
               Email
               Management System Alert
               Custom Program Alert
               Offline Configuration w/GUI
MANAGEMENT SOFTWARE-
               WatchGuard System Manager (WSM)
NOISE LEVEL  - 54 dBA at 20 - 25 degrees C
POWER SOURCE - 100-240 VAC autosensing, 50/60 Hz; Consumption 60 watts
DIMENSIONS   - 16.75"w x 1.75"h x 14.25"d       WT.- 9.68 lbs.
               Rack mountable
