| Manufacturer |
U.S. Robotics. |
| Manufacturer Part Number |
USR5453 |
| Product Name |
5453 Professional Access Point |
| Marketing Information |
The
5453 Professional Access Point delivers a powerful array of features
designed to provide flexible, managed IEEE 802.11g/IEEE 802.11b
connectivity for small/medium businesses. The management interface has
been designed to allow customers to manage an entire cluster of access
points (APs) directly, or with integrated SNMP functionality, by using
a standards based network management system.
|
| Product Type |
Wireless Access Point |
| Product Model |
5453 |
|
| Wireless Technology |
IEEE 802.11b/g |
| Antenna |
2 x 5dBi Swivel Dipole Antenna Detachable with
Reverse Polarity SMA Connectors |
| Frequency Band/Bandwidth |
2.4 GHz to 2.462 GHz IEEE 802.11b/g ISM Band
North America |
| Channel(s) |
11 Channel(s)Operating North America |
| Transmission Speed |
54Mbps |
| Transmission Speed Details |
54Mbps Auto-fallback IEEE 802.11g
6Mbps IEEE 802.11g
11Mbps Auto-fallback IEEE 802.11b
1Mbps IEEE 802.11b
|
| Wireless Security |
TKIP
AES Encryption
MAC Address Filtering
IEEE 802.1x authentication
Wi-Fi Protected Access 2 (WPA2)/IEEE 802.11i
Wired Equivalent Privacy (WEP) encryption length: 64/128-bit
|
|
| Interfaces/Ports |
1 x RJ-45 10/100Base-TX Auto-sensing |
|
| Management |
Easily managed with web interface
SNMP: MIB1, MIB II, Bridge MIB, 802.11 MIB, Client Radio
Stats, Firmware upgrade, Reset, RF Channel Management (read only)
Monitoring: AP-Location, Status, Firmware and configuration,
Throughput, Security; System Log Capture, RF Interference, Clients
|
| Security |
Neighbor AP Detection
HTTP Redirection for guest/login
Multi-SSID/Multi-BSSID (4 Beacons)
VPN Passthrough: IPSec, L2TP & PPTP
VLAN tagging - pass through and association with BSSID
Mini-radius (100 user embedded authentication: EAP, PEAP)
|
|
| Form Factor |
Wall-mountable
Desktop
|
| Dimensions |
4.3" x 7.1" x 1.7" |
| Weight |
0.61 lb |
|
| Package Contents |
5453 Professional Access Point
Ethernet Cable
Power Adapter
Quick Installation Guide
Two 5 dBi Swivel Antennas
Installation CD-ROM with User Manual
|
| Additional Information |
Repeater Mode (WDS)
Bridging/Multi-bridging (WDS)
|
| Certifications & Standards |
Wi-Fi
IEEE 802.1x
IEEE 802.11i
IEEE 802.11d
IEEE 802.11b
IEEE 802.11g
Safety: UL, CUL
EMI: FCC Class B
EMI & Safety: CE Class B
|
|
| Standard Warranty |
2 Year(s) Limited |
