Product Description:
General Manufactures Description Page
Manufactures
Part Number
|
| FS-C77 |
Features
|
- Pure copper heatsink with ultra large surface area for
maximum cooling performance.
- 80mm fan (with red LEDs) installed in the heatsink (FHS)
cools not only the VGA chipset and VGA RAM, but all other VGA
components as well.
- Quiet Mode(5V) and Performance Mode(12V) selection provided
to accommodate the user's environment and preference.
|
Included
|
- Heatsink Assembly (FS-V7)
- Eight RAM Heatsinks
- One Brace Plate
- Two Nipple A
- Two Nipple B
- Four Bolt A
- Four Bolt B
- Six Rubber Rings
- Thermal Grease
- One Muti-Connector
- User's Manual
|
Specifications
|
| Dimensions |
: 91(L) x 126.4(W) x 30(H)mm |
| Weight |
: 270g |
| Base
Material |
: Pure Copper |
| Bearing
Type |
: 2 Ball-Bearing Sets |
| Speed |
: 2,050 rpm ± 10% (Quiet Mode), 3,500 rpm
± 10% (Performance Mode) |
| Noise
Level |
: 23.7 dB ±10% (Quiet Mode), 36dB ±10%
(Performance Mode) |
|
|
