Wireless Ready
In a mixed network of wired and wireless environments, predictable coverage and security become paramount. The need for a switching solution capable of addressing these needs in both the wired and wireless environment becomes key. The DXS-3250 is capable of meeting this demand and more. With a simple optional firmware upgrade, the DXS-3250 transforms from a standard Layer 2 switch into an integrated wired and wireless switching solution capable of providing powerful wireless security, easy deployment, the ability to detect rogue access points, and centralized management for all compatible WLAN components. Centralized management has become crucial for wireless technologies deployed in real-time inventory, data mining, and an array of personal electronics that demands mobility and seamless integration such as PDA and 3G/VOIP mobile phones. With an optional software upgrade, the DXS-3250 becomes a wireless switch providing secure, seamless roaming between access points ensuring clear, uninterrupted data and voice communication throughout your wireless network infrastructure.

Comprehensive Security
The DXS-3250 is equipped to handle many of today’s emerging security vulnerabilities previously delegated to only stand-alone firewalls. It incorporates built in ACLs for searching out and filtering such threats as: Denial of Service attacks, Trojan Horses, Worms, and more. Other access rules can also be set up to prevent network, and 802.1x authentication login. In addition, port based security can also be set up to protect the integrity of the network. Furthermore, the DXS-3250 protects against attacks towards the CPU itself, and improves utilization to meet existing network demands to maximize device responsiveness to user configuration activities. In addition, well-known port numbers for allowed applications can be pre-programmed, which will allow these applications faster service, and reduce the load on the CPU.

High Availability
The DXS-3250 supports “Shortest-Path” switching which improves resiliency, uptime and network efficiency. It also supports an optional Redundant Power Supply (DPS-600). It includes support for 802.3ad Link Aggregation, and 802.1w Rapid Spanning Tree for increased network reliability and availability.

Network Management
The DXS-3250 features a variety of network management options: console CLI, telnet, web GUI, SNMPv1/v2/v3, and RMON. It also supports a variety of advanced traffic management options including: Layer 3 static routing, Bandwidth Control, Broadcast Storm Control, Private VLANs, and support for IGMP Snooping. D-Link’s exclusive stacking technology is also supported, which allows up to 16 D-Link DXS-3250 switches to be stacked together and managed as a single unit, regardless of its physical environment.

Advanced QoS
The DXS-3250 provides a robust and consistent set of QoS/ CoS, supporting 8 priority queues for 802.1p/ToS/DiffServ, with classification and marking based on MAC SA/DA, IP SA/DA, and/or TCP/UDP. It also provides extensive support for GARP/GVRP, 802.1q, and port-based VLANs for up to 4000 groups per device.

• ‘Wireless-ready’ Switching
• Stacks Up to 16 Units Per Stack
• Optional Dual 10-Gig Stacking or Uplink Ports
