Product Description:
| Marketing Description: IOGEAR's new eight-port Miniview Ultra+
KVM switch is the ideal tool to help reduce redundant hardware. Eight
monitors, mice and keyboards are simply too expensive, bulky and
inconvenient for most system administrators. Why bother when you can
control all eight, or even up to 512 computers with a single keyboard,
monitor and mouse? The added audio support allows you to enjoy music
while working. Just think of the time, space and money you'll save, and
added fun. The New Miniview Ultra+ is much more than a simple
eight-port KVM switch. The dual interface support allows you to connect
both PS/2 and USB computers on the same switch. The multi-platform
support allows you to control Windows-based computers, Sun Solaris
systems, Linux, or even Macs by a single KVM switch. IOGEAR extended
the multi-platform support by supporting the special keys on both Sun
and Mac keyboards. This KVM switch also comes with the IOGEAR VSE
technology, which provides excellent video resolution - up to 2048 x
1536. Built-in AutoScan mode lets you conveniently monitor every
attached computer for a specified amount of time, while our On Screen
Display (OSD) technology allows you to assign a unique name to each
computer and access it via a smooth menu-driven interface. With its 1U,
19" rack-mountable casing and status-monitoring LEDs, the Miniview
Ultra+ is the perfect switch for your server room or any other
multi-computer environment. |
| Product Description |
IOGear MiniView Ultra+ GCS1758 - KVM / audio switch - 8
ports |
| Device Type |
KVM / audio switch |
| Form Factor |
Rack-mountable - 1 U |
| Dimensions (WxDxH) |
17 in x 6 in x 1.7 in |
| Ports Qty |
8 |
| KVM Users Qty |
1 local user |
| General |
| Device Type |
KVM / audio switch |
| Enclosure Type |
Rack-mountable - 1 U |
| Width |
17 in |
| Depth |
6 in |
| Height |
1.7 in |
| Networking |
| Ports Qty |
8 |
| Connectivity Technology |
Wired |
| Status Indicators |
Status |
| KVM |
| KVM Local Users Qty |
1 local user |
| Max Resolution |
2048 x 1536 |
| Expansion / Connectivity |
| Interfaces |
8 x keyboard / video / mouse (KVM) - 15
pin HD D-Sub (HD-15)
8 x audio - line-out - mini-phone stereo 3.5 mm
8 x microphone - input - mini-phone 3.5 mm |
| Connections |
2 x USB - 4 pin USB Type A - 2
1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x audio - line-out - mini-phone stereo 3.5 mm - 1
1 x microphone - input - mini-phone 3.5 mm - 1 |
| Miscellaneous |
| Cables Included |
1 x data cable |
| Rack Mounting Kit |
Included |
| Compliant Standards |
DDC-2B |
| Power |
| Power Device |
Power adapter - external |
|
|
