Camera Specifications

Video Source

Embedded CCD

Image Sensor

1/4 inch color CCD image sensor

Lens Type

10x Optical Zoom Lens with 4.2~42 mm focal length, F1.8~2.9

CCD Resolution

Minimum Illumination

1 Lux / F1.8 (0.05 Lux / F1.8 in Low Lux Mode)

Electronic Shutter Speed

1/60 ~ 1/120,000 second NTSC

Automatic Electronic Shutter (AES)

Supported

Automatic Gain Control (AGC)

Supported

Automatic White Balancing (AWB)

Supported

Auto-Iris Support

Built-in Auto-Iris

Dimensions

105.0 mm Length

105.0 mm Width

125.0 mm Height

Weight

Net 429g

System

CPU

Trimedia PNX1300

RAM

16MB SDRAM

ROM

2MB FLASH ROM

Video Specifications

Algorithm Supported

Dual Codec: MPEG4 (Short Header Mode) and MJPEG

Average Compression Ratio

150 ~ 200 (MPEG4) / 12 ~ 20 (MJPEG)

Frames Per Second

Up to 30 / NTSC

Max Video Resolution

704 x 480 / NTSC

Resolution NTSC

Up to 30 frames per second at 176 x 120

Up to 30 frames per second at 352 x 240

Up to 15 frames per second at 704 x 480

Features

Adjustable image size, quality and bit rate

Time Stamp and Text Overlay

Up to 3 motion detection windows

10x Optical Zoom, 10x Digital Zoom

Upload Snapshots (FTP or Email)

Networking

Protocol

TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DDNS, UPnP and DHCP

Ethernet

10 baseT or 100baseT Fast Ethernet auto negotiation

Pan/Tilt/Zoom

Pan Range:

±135°, 10°~50°/sec

Tilt Range:

+90°~ -45°, 7°~25°/sec

Zoom:

1x~10x Optical Zoom

2x, 4x, 6x, 8x, 10x Digital Zoom

Features

Auto Pan mode, Auto Patrol mode

Miscellaneous

Audio Frequency

8/24/32 Kbps

Full Duplex Audio Communication

Microphone

Omni-directional

Frequency: 20 ~ 20,000 Hz

S/N Ratio: More than 58 dB

General I/O

1 sensor input (max. 12V DC 50mA)

1 relay output (max. 24V DC 1A / 125V AC 0.5A)

LED Indicators

Dual color system status indicator

Power

Consumption

Maximum 12W

Output

12V DC, 1.5A

Input

100 ~ 240V AC, 50/60 Hz, 0.4 A

Operating Environment

Operating Temperature

0 ~ 40°C (32 ~ 104°F)

Operating Humidity

85% RH

EMI & Safety

Certification

CE, FCC

System Requirements

Operating System

Microsoft Windows 98SE/ME/2000/XP

Browser

Internet Explorer 5.x or above

Bundled Software

IPNV16 Security and Remote Monitoring Software

Remote configuration and control of up to 16 devices

Fast/Slow forward, replay and pause

Scheduled backup

Event-triggered, Scheduled and Manual recording

Instant search with preview windows

Hard disk quota warning

AVI format export
