Features

• Accepts both 3U PXI and CompactPCI modules
• One system slot and 5 PXI/CompactPCI peripheral slots
• PXI specifications Rev. 2.0 compliant
• Filtered, forced-air cooling
• Side handles and stand feet for portability
• Modular AC or DC 250 W power supply
• IEEE 1101.10 mechanical packaging compliant
• Wall mount/Panel mount kit included

Introduction

ADLINK PXIS-2506 is a 3U 6-slot portable PXI chassis. The chassis provides 5 PXI/CompactPCI peripherals slots, and is compliant with the PXI and CompactPCI specifications. Both PXI and CompactPCI modules could be used in the chassis. Coming with the PXI specifications, the internal 10 MHz reference clock is available on all of the 5 PXI slots, as well as the functionalities of star trigger, PXI trigger bus and PXI local bus. The standard PXIS-2506 chassis is equipped with industrial-grade 250 W CompactPCI power supply, cPS-H325/AC, to provide reliable power to the system. DC input power modules are available. ADLINK also provides OEM version PXIS-2556(provides a 6.4" TFT LCD display) & PXIS-2556T(provides touch panel with the 6.4" LCD display) for customized application. ADLINK PXD-3710 (3-slot version, without floppy disk drive), the system controller, is designed to fit in the PXIS-2556/2556T series chassis. Wall mount/Panel mount kit is included in the standard package.
