MODEL- ACS1216AKIT        VENDOR- ATEN TECHNOLOGY

FEATURES- 1U Maxiport Slim 16-Port KVM Switch Kit
       The Maxiport 16-port KVM Kit allows you to access and control up to
        512 computers from a single keyboard/monitor/mouse console. It also
        comes with many great features such as Hot key control, On Screen
        Display (OSD), keyboard and mouse emulation, and Flash ROM for
        firmware upgrade.
    Includes KVM Switch (ACS1216AL), (8) 6 foot KVM cables (2L5202P),
      (8) 10 foot KVM cable (2L5203P), firmware upgrade cable, power
      adapter, rack mounting kit, user manual.
* A single console controls up to 16 computers
* Daisy chain up to 31 additional units - Control up to 512 computers from
  a single console.
* Auto-sensing of station position on daisy chained installations - No need
  for manual DIP switch setting - Front panel LED indicates station
  position.
* Port names automatically reconfigured when station sequence is changed.
* No software required - Convenient computer selection via intuitive on
  Screen Display (OSD) menus.
* AutoScan feature for monitoring user-selected computers
* Hot pluggable - Add or remove computers without having to power down the
  switch.
* Two level password security - Only authorized users view and control the
  computers - Up to four users plus an administrator - Separate profiles
  for each.
* Two level logout - Manual and timed
* Firmware upgrade through Flash ROM
* PS/2 keyboard and mouse emulation - Computers boot even when the console
  focus is elsewhere.
* Supports PS/2 compatible mice, Microsoft Intellimouse Explorer, Logitech
  FirstMouse+.
* Superior video quality - Supports resolutions of up to 1920 x 1440.
* Rack mountable in 19" system rack (1U)
* 16 cables included (eight 6  and eight 10 )

  -- SPECIFICATIONs -----------------------------------
CONNECTORS   - Computer   : (16) DB15F (for keyboard, mouse, monitor)
               Console    : ( 1) 6-pin mini-DIN F (for keyboard)
                            ( 1) HDB-15 F (for monitor)
                            ( 1) RJ-11 (for flash ROM upgrade)
                            ( 1) 6-pin mini-DIN F (for mouse)
               Daisy Chain: ( 1) DB-25M
                            ( 1) DB-25F
EMULATION    - Mouse   : PS/2
               Keyboard: PS/2
INDICATORS   - LEDs for On-Line, Power On, Selected, Station ID
SCAN INTERVAL- User specified: 1 ~ 255 seconds
PORT SELECTION-
               Hotkeys; OSD (On-Screen Display)
VIDEO RESOLUTION-
               1920 x 1440; DDC2
REQUIREMENTS - Console: A VGA, SVGA, or Multisync monitor capable of the
                          highest resolution that you will be using on any
                          computer in the installation.
                        A PS/2 mouse
                        A PS/2 keyboard
               The following equipment must be installed on each computer:
                        A VGA, SVGA or Multisync card
                        A 6-pin mini DIN (PS/2) port
                        Either a 6-pin mini DIN (PS/2) keyboard port, or a
                          5-pin DIN (AT) keyboard port.
POWER- DC 9V; 8.0 W (max.)
SIZE - 17.0"w x 1.75"h x 6.2"d                WT.- 6 lbs.
