MODEL- RRAID1640          VENDOR- HPT USA/HIGHPOINT TECH

FEATURES- RocketRAID 1640 4-Channel Serial ATA RAID Adapter
       The RocketRAID 1640 is a four-channel RAID 5 host adapter, which
        provides multi-level RAID support, including RAID 5, 0, 1, 1/0,
        JBOD, as well as powerful software management functions. The
        RocketRAID 1640 Serial ATA RAID host adapter increases disk
        performance to 1.5Gb/s, and supports most of today's popular OSs'
        such as Windows 9x/ME/NT4.0/2,K Windows XP, Red Hat, SuSE, Turbo,
        Caldera Linux and FreeBSD.
       As a high-performance, affordable RAID solution, the RocketRAID 1640
        is well suited for nearly any corporate, industrial, or home
        environment application. The RocketRAID 1640 Serial ATA RAID host
        adapter is ideal for small LAN servers, critical business data
        storage, PC gaming, and high-end personal storage needs. The
        RocketRAID 1640 is not only able to connect with Serial ATA hard
        disks, but also can be utilized with standard IDE hard disk drives
        (when used in combination with the RocketHead100 converter).
       The RAID Management software can be used to control remote systems,
        over a network. The administrator can manage several different
        remote systems that utilize other HighPoint RAID controllers, from
        a single PC. The software provides options to create, maintain,
        delete and modify RAID arrays.
    Includes RocketRAID 1640 card, (4) Serial ATA cables, Driver software,
      RAID Management software (Windows version), User's manual.

  -- SPECIFICATIONs -------------------------------------
HOST SIDE INTERFACE    - 32-bit 33MHz PCI
DISK INTERFACE         - SATA/IDE
# OF IDE CHANNELS      - 4 Channels
MAX. NUMBER OF DRIVES  - 4 hard drives
SUPPORTED HARD DRIVES  - Serial ATA hard disks, IDE hard disk drives (with
                          optional RocketHead 100 converter).
RAID LEVEL SUPPORT     - RAID 5, RAID 0, RAID 1, RAID 10 (1/0) and JBOD
O/S SUPPORT            - Windows 98/ME/NT 4.0/2K/XP/2003
                         Linux (SuSE, Red Hat, Caldera, Turbo), and FreeBSD
RAID MANAGEMENT TOOL   - RAID Configuration and Management
GUI FUNCTION           - RAID Configuration and Management (compatible with
                          BIOS).
MISC. FEATURES         - Automatic e-mail notification when error occurs.
                         Bootable array support.
                         Large LBA support capacity exceeding 137GB.
www.highpoint-tech.com
