| Access Method |
CSMC/CD, 10Mbps and 100
Mbps |
| Standard Conformance |
- IEEE802.3 10Base-T
- IEEE802.3u 100Base-TX, 100Base-FX
- IEEE 802.3z 1000Base-T, 1000Base-SX
|
| Number of Ports |
16 x RJ-45 MDX ports |
| Network Media (Cable) |
- 10Base-T:UTP category 3,4,5 cable
- 100Base-TX:UTP category 5 cable
|
| Switch Mechanism |
- Filtering: Forwarding and learning
- Switching Method: Store-and-Forward Maximum
- Bandwidth: 4800Mbps
- Filtering Rate: Line Speed/Forwarding Fate: Line Speed
|
LED Indicators System
(Each Port) |
- Power
- 100M and 10M Link/Activity
- Full Duplex/ Collision
|
| Physical Dimension |
- ZFS3016B-05: 37x 250 x120mm
- ZFS3016-06: 199x 443 x 42 mm
|
| Input Power |
- ZFS3016B-05: 100-240V .4A Max
- ZFS3016-06: 90-254V 1.0A Max
|
| Temperature |
- Operation: 0°C ~ 50°C (32°F ~ 122°F)
- Storage: -40°C ~ 70°C (-40°F ~ 158°F)
|
| Humidity |
- Operation: 10~90% (Non-Condensing) RH
- Storage: 5% to 90% RH
|
| Registration |
FCC, CE |
| Manufacture Warranty |
Three (3) Year Limited Manufacturer Warranty |
