USB Features |
Ports |
4 or 7 USB Type A ports (USB 2.0, 1.1 and 1.0 compatible) |
Data Rate |
480 Mbps (on USB 2.0 models); Multi-TT switched USB architecture guarantees a full 12 Mbps simultaneously on all downstream ports, even if a high-speed 480 Mbps transfer is active |
Cables |
Includes 1-meter USB cable |
General Features |
Power |
Individual port power management; 10-26VDC powered models for mobile applications; 500 mA downstream power available per port; Locking power connector |
Operating Systems |
Linux®, Windows Vista®, Windows Server® 2008, Windows XP®, Windows® XP Embedded, Windows NT® 4.0*, Windows NT Embedded*, Windows CE, Windows Server® 2003, Windows 2000
*Supported when connecting Digi products. |
LEDs |
System power, Port status
(4-port models: 5 LEDs; 7-port models: 8 LEDs) |
Dimensions (L x W x H) |
Hubport/4c, Hubport/ 4c DC, Hubport/7c, Hubport/7c DC:
2.61 in x 3.00 in x 1.00 in (6.63 cm x 7.62 cm x 2.54 cm)
Hubport/4cM, Hubport/4cM DC:
3.74 in x 3.00 in x 1.39 in (9.50 cm x 7.62 cm x 3.53 cm) |
Other |
No additional IRQ or memory address requirements; Hot-swappable; Rack-mountable; Plug and Play; Metal enclosures and DC-powered models available |
Power Requirements |
Power Input (AC Models) |
Ships with plug-mounted 120/230VAC 60/50 Hz at 5VDC @ 3Amps max |
Power Input (DC Models) |
Accepts 10 - 26VDC input |
Environmental |
Operating Temperature |
0° C to 55° C (32° F to 131° F) |
Relative Humidity |
0% to 95% (non-condensing) |
Approvals |
Safety |
EN60950, UL 1950, CSA 2.2 No. 950, IEC 950 |
Emmissions/Immunity |
CE, FCC Part 15, Class B, EN55022 Class B, EN55024 |
