Product Description:
For many industrial automation applications, redundancy helps increase the reliability of your system. To create reliability in your network, the EKI-7559 Series come equipped with a proprietary redundant network protocol -- X-Ring that was developed by Advantech, which provides users with an easy way to establish a redundant Ethernet network with ultra high-speed recovery time less than 10 ms. Furthermore, EKI-7559 Series also supports many advanced network standards to optimize network performance, ease maintenance issues, and secure network safety.
- 2 x SC-type fiber ports, plus 8 Fast Ethernet ports
- Redundancy: X-Ring (high-speed recovery time<10ms), RSTP/STP
(802.1w/1D)
- Management: Web, Telnet, Serial Console, Windows Utility, SNMP
- Control: VLAN/GVRP, QoS, IGMP Snooping/Query, LACP, Rate Limit
- Security: IP/MAC, port binding, DHCP Server, IP access list,
802.1X, SNMPv3
- Diagnostic: Port Statistic, Port Mirroring, RMON, Trap, Email
Alert, Syslog
- Dual 12 ~ 48 VDC power input and 1 Relay Output
- Robust mechanism and special heat spreader design
Specifications
General |
Ethernet Connectors |
4 x RJ-45 + 2 x SC-type
fiber optic connector |
Mounting |
DIN-rail, Wall |
I/O |
Transmission Distance |
Ethernet: Up to 100 m
(4-wire Cat.5e, Cat.6 RJ-45
cable suggested for Gigabit port)
Gigabit Fiber: Up to 110 km
(depending on SFP) |
Transmission Speed |
Ethernet: 10/100Mbps Auto-Negotiation
Gigabit Copper: 10/100/1000 Mbps,
Auto-Negotiation
Gigabit Fiber: Up to 1000Mbps |
Operating System |
Operating Temperature |
-10 ~ 60°C (14 ~ 140°F) |
Power Supply |
Power Connector |
- |
Power Input |
2 x Unregulated
12 ~ 48 VDC |
|
