Product Description:
The N-TRON 524TX twenty-four port Industrial Ethernet Switch
offers outstanding performance and ease of use. It is ideally suited
for connecting Ethernet enabled industrial and/or security equipment
and can be optionally configured with advanced Ethernet
communication management functions
Features:
- Full IEEE 802.3 Compliance
- Twenty-Four 10/100 BaseTX RJ-45 Ports
- -40º to 85º C Operating Temperature
- Autosensing 10/100BaseTX, Duplex, and MDIX
- Up to 2.6 Gb/s Backplane
- Rugged Industrial Rack mount Enclosure
- Redundant Power Inputs (10-30 VDC)
- Bi-Color LED's For Link, Speed, Activity & Duplex Status
- Optional Advanced Management Features
Specifications:
Switch Properties
- Number of MAC Addresses: 12,000
- Aging Time: 300s (programmable -A)
- Latency Typ.: 2.1 μs
- Backplane Speed: 2.6Gb/s
- Switching Method: Store & Forward
Physical
- Height: 1.75" (1 U)
- Width: 19"
- Depth: 4.34"
Electrical
- Redundant Input Voltage: 10-30 VDC
- Input Current: 800 mA@24V
- Inrush: 9.5Amp/0.75ms@24V
Environmental
- Operating Temp: -40oC to 85oC
- Operating Humidity: 10% to 95% (Non Condensing)
- Operating Altitude: 0 to 10,000 ft.
Shock and Vibration
- Shock: 200g @ 10ms
- Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
Network Media
- 10BaseT: >Cat3 Cable
- 100BaseTX: >Cat5 Cable
Serial Configuration Port
- Com Parameters: 9600,n,8,1
Recommended Wiring Clearance
|
