System

• Form Factor
  Mini-ITX
• Processor
  Supports Intel Pentium M / Celeron M processors, up to 2.0GHz with FSB 400MHz or onboard Intel LV/ ULV Pentium M/ Celeron M processors
• System Memory
  184-pin DDR DIMM x 1, Max. 1GB (DDR 266)
• Chipset
  Intel 852GM + ICH4
• I/O Chipset
  ITE 8712 + Fintek F81216
• Ethernet
  Realtek 8100C ,10/100Base-TX RJ-45 connector x 1
• BIOS
  AWARD 512KB FLASH ROM
• Wake On LAN
  Yes
• Watchdog Timer
  Generates a time-out system reset
• H/W Status Monitoring
  Supports power supply voltages, fan speed and temperature monitoring
• Solid Storage Disk
  Type II CompactFlash slot x 1
• Expansion Interface
  Mini PCI x 1, PCI x 1, PCMCIA
• Battery
  Lithium battery
• Power Requirement
  +5V/ AT/ATX
• Power Consumption (Typical)
  Intel Pentium M 2.0 GHz, DDR 400 1GB
  4.89 A@+5V
• Board Size
  6.7"(L) x 6.7"(W) (170 mm x 170 mm)
• Gross Weight
  1.1 lb (0.5 kg)
• Operating Temperature
  32^oF~ 140^oF (0^oC ~ 60^oC)
• Storage Temperature
  -40^oF~176^oF (-40^oC~80^oC)
• Operating Humidity
  0% ~ 90% relative humidity, non-condensing
• MTBF (Hours)
  71,415

Display: Supports CRT/LCD, CRT/TV, CRT/DVI, LCD/DVI and LCD/TV simultaneous display ; Supports CRT/LCD, CRT/TV, CRT/DVI, LCD/DVI and LCD/TV dual view

• Chipset
  Intel 852GM
• Memory
  Shared memory up to 64MB with DVMT
• Resolutions
  Up to 1280 x 1024 @ 32 bpp colors for CRT
  Up to 1280 x 1024 @ 24 bpp colors for LCD
• LCD Interface
  Up to 48-bit dual channel LVDS
• TV-out
  Supports NTSC and PAL standard

I/O

• MIO
  UDMA100 x 1, UDMA33 x 1, Floppy Disk Drive x 1, PS/2 Keyboard x 1, PS/2 Mouse x 1, RS-232 x 5, RS-232/422/485 x 1, Parallel x 1
• IrDA
  One IrDA Tx/Rx header
• Audio
  MIC-in, Line-in, Line-out, or 5.1 Output
• USB
  One Type-A (dual) connector supports 2 USB 2.0 ports ( External)
  One 5x2 pin header supports 2 USB 2.0 ports (Internal)
• Digital I/O
  Supports 8-bit (programmable)
