Product Description:
description
The PCI-1261 realizes 6-axis asynchronous/synchronous control with DDA
(Digital Differential Analyzer) manner delivers movement of each axis
evenly. At pulse output control, it can also read back motor encoder
value via encoder input port. In the control of each axis, there is a
set of sensor input points, including home points, plus limit points
and minus limit points. Further, there are servo-on signal output
points, position ready output point and emergency stop input point. For
advanced applications, we supply Windows DLL drivers and user-friendly
examples to decrease your programming load. Moreover, through a free
bundled PCI-1261 motion utility, you can complete configuration and
diagnosis easily.
Features:
PCI bus interface
Asynchronous/synchronous 6-axis
motion control
Linear, helical interpolation
functions
2/3-axis arc, circle interpolation
functions
Jog functions
Continuous interpolation functions
T/S-curve acceleration/decelerations
Constant speed and over speed control
In position and compensation functions
Go home functions
Position management and software
limit switch functions
Event trigger functions
19 dedicated inputs and 7 dedicated
outputs
Up to 4 MPPS pulse output for each
axis
|
|
