Product Description:
MODEL- JJ-P04111-S6 VENDOR- SIIG
FEATURES- Quartet Serial Plus PCI
Four 16650 serial port I/O card with 4-port (DB9) fan-out cable!
Supports 32-/64-bit, 3.3V/5V PCI and PCI-X slots.
Four high-speed 16650 UART serial ports (9-pin) support data rate up
to 460 Kbps.
Will work as standard RS232 port or with 5V or 12V power output for
devices that require power (such as handheld scanners, table
scanners, POS displays, etc.). Configurable via jumpers with silk-
screened settings on PCB.
Includes Quartet Serial Plus PCI, Mini 4-port fan-out cable (33-inch),
Driver CD and User's manual.
* IRQ sharing reduces IRQ conflicts.
* Built-in 64-byte FIFO buffers dramatically increase data transmit/receive
speed, especially under Windows multitasking environment.
* 4-layer PCB board: separate layers for data & grounding. Greatly reduces
signal noise & loss. Delivers more reliable high-speed data transfers.
* Enhanced bracket design to prevent bending. Connected to PCB with
washered screws for a more secure connection.
* Supports 3.3V operation with 5V tolerance.
* Conforms to PCI v2.2 universal card standard. PCI-X & 64-bit compatible.
* Supports PME # (Power Management Event). Allows device to request a
change in system power state (wake up system).
* Use SMT (Surface Mount Technology) type electrolytic capacitor. Low ESR
(Equivalent Series Resistance) aluminum electrolytic capacitor. Offers
much improved noise suppression & achieves higher levels of performance/
reliability.
* Use SMT (Surface Mount Technology) type crystal. Offers cleaner design
than traditional DIP-type crystal. Provides greatly improved grounding,
which reduces EMI emission & improves performance/reliability.
-- SPECIFICATIONs ----------------------------------
INTERFACE/BUS- 32-bit PCI
CHIPSET - CyberPro
CONNECTORs - (4) DB-9/RS-232 Serial ports
APPROVALS - FCC B (DoC) & CE, RoHS compliant
REQUIREMENTS - Pentium or equivalent computer with an available 32-/64-bit
PCI or PCI-X slot.
Windows 95/98/98SE/ME/NT 4.0/2000/XP (32-/64-bit)/Server
2003 (32-/64-bit)/Vista (32-/64-bit).
