Manufacturer |
Tripp Lite |
Manufacturer Part Number |
OMNI650LCD |
Manufacturer Website Address |
www.tripplite.com |
Product Series |
OmniSmart |
Product Model |
OMNI900LCD |
Product Name |
OmniSmart 650 VA Rack-mountable Tower Digital UPS |
Marketing Information |
Rotatable liquid crystal display (LCD) status screen shows
input voltage and operating conditions in real time
Power button offers convenient, one-touch power control
|
|
Plug/Connector Type |
NEMA 5-15P |
Receptacles |
4 x NEMA 5-15R - Backup/Surge-protected
4 x NEMA 5-15R - Surge-protected
|
|
Load Capacity |
650VA / 350W |
Input Voltage |
110V AC |
Input Voltage Range |
120V AC Nominal |
Output Voltage |
120V AC Nominal |
Frequency |
60Hz Input
60Hz Output
|
Waveform Type |
Pulse-width Modulated Sine Wave |
Surge Energy Rating |
480J |
Filtering |
EMI/RFI |
|
Audible Alarms |
Self-test Operation |
|
Status Indicators |
Input Voltage : Shows actual incoming voltage in real time
Battery Charge : Shows approximate charge available on the
battery
Automatic Voltage Regulation (AVR) : Illuminates to indicate
the UPS is automatically regulating incoming voltage without draining
battery power
Battery Recharge/Replace : Illuminates to indicate the UPS
batteries need to be recharged or replaced (following a self-test)
Battery Backup : Illuminates to indicate that the UPS is
supplying battery power to connected equipment
Output Load Level : Illuminates when the electrical load of
connected equipment exceeds the capacity of the UPS
|
|
Interfaces/Ports |
1 x USB 4-pin |
|
Backup/Run Time |
5 Minute(s) Full-load
15 Minute(s) Half-load
|
Battery Recharge Time |
8 Hour(s) |
|
Temperature |
32 °F (0 °C) to 104 °F (40 °C) Operating
5 °F (-15 °C) to 122 °F (50 °C) Storage
|
Humidity |
0 to 95% Non-condensing Relative Humidity |
|
Color |
Black |
Form Factor |
2U Rack-mountable Tower |
Power Cord/Cable |
6 ft |
Dimensions |
12" Height x 3.5" Width x 6.5" Depth |
Shipping Dimensions |
6.5" Height x 15.5" Width x 11" Depth |
Weight |
14.6 lb |
Shipping Weight |
15.6 lb |
|
System Requirements |
PowerAlert Software (available on website ) to
automatically and safely shut down your computer or PC receiver during
blackouts. |
Country of Origin |
China |
