Standards
|
|
|
EIA/TIA-232,
EIA/TIA-574 & CCITT V. 28
|
Ports
|
|
|
1 x Serial
RS-232 (DB9 Male)
|
|
1 x Fiber
(SC ; Multi-mode)
|
Max. Distance
|
|
Copper
|
15 meters
|
Fiber
|
Up to
120Km (Single Mode)
|
Data Rates
|
|
Serial
|
115.2 kbps
(Asynchronous)
|
Signals
|
|
RS-232
|
TxD, RxD,
GND
|
Unit LED
|
|
PWR
|
Green :
Illuminated for normal operation
|
LNK
|
Green :
Illuminated when receiving link pulse from compliant
|
RCV
|
Amber :
Illuminated when receiving packets from DTE or DCE
|
Power
|
|
Power Input
|
9~48V DC /
1A
|
Temperature
|
|
Operating
|
0 C to 50 C
|
Storage
|
-20 C to
80 C
|
Humidity
|
|
Operating
|
10% to 80%
, non-condensing
|
Storage
|
5% to 90%
, non-condensing
|
Emissions
|
|
|
FCC Part
15 of Class A & CE approved
|
Dimensions
|
|
|
100 x 50 x
120mm (D x W x H)
|
