Specifications

• Mfr Part Number: FD-C-DEF7A-01
• Features:
  • Dual-layout interior easily fits motherboards up to 285 mm E-ATX
  • New chassis design opens to fully expose the interior on three sides
  • Impressive water-cooling with support for radiators up to 420mm
  • Supports up to 14 x 3.5â€? HDDs and 4 x 2.5â€? SSDs in Storage Layout
  • Silence-optimized construction with industrial sound-damping
  • Top panel effortlessly swaps from sound dampened solid steel to filtered ventilation
  • Aluminum front panel with dual-handed hinges and magnetic latching
  • 9 x 140/120mm fan positions with 3 x Dynamic X2 GP-14 fans included
  • Tool-less, top-latching panels on both sides
• Case Type: ATX Mid Tower
• Color: Black
• Material: Steel
• With Power Supply: No
• Power Supply Mounted: Bottom
• Power Supply: ATX
• M/B Type: E-ATX / ATX / MicroATX / Mini-ITX
• Side Panel Window:​ yes
• Drive Bays:
  • External Bay: 1x 5.25"
  • Internal Bay: 6x 3.5"  2x2.5"
• Expansion Slots: 7 + 2 vertical
• Front Ports: 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O
• Fan Options:
  • Total fan mounts: 9 x 120/140 mm
  • Front: 3 x 120/140 mm (2 x Dynamic X2 GP-14 included)
  • ​Top: 3 x 120/140 mm
  • Rear: 1 x 120/140 mm (1 x Dynamic X2 GP-14 included)
  • Bottom: 2 x 120/140 mm
• Radiator Options:
  • Front:  Up to 360/280 mm
  • Top: Up to 360/420 mm
  • Bottom: Up to 240/280 mm
  • Rear: 120 mm
• Dimensions & Weight:
  • Max GPU Length: 491 mm
  • Max CPU Cooler Height: 185 mm
  • Max PSU Length: 250 mm (with HDD cage installed)
  • Case Dimensions (LxWxH): 547 x 240 x 475 mm; 533 x 240 x 451 mm w/o feet/protrusions/screws
  • Weight: 13.45 kg
  • Package Dimensions (LxWxH): 558 x 363 x 641 mm
  • Package Weight: 15.94 kg
