General |
Device Type |
UPS |
Form Factor |
External |
Width |
7.2 in |
Depth |
7.5 in |
Height |
11.7 in |
Weight |
32.2 lbs |
Power Device |
UPS Technology |
Line interactive |
Supported Battery Technology |
Lead acid |
Input Voltage |
AC 120 V |
Input Voltage Range |
AC 75 - 147 V |
Frequency Required |
60 Hz |
Input Connector(s) |
1 x power NEMA 5-15 |
Output Voltage |
AC 120 V ( 60 Hz ) |
Output connector(s) |
8 x power NEMA 5-15 |
Power Output Connectors Details |
6 x power NEMA 5-15 ( UPS and surge )
2 x power NEMA 5-15 ( surge ) |
Power Provided |
1500 VA |
Dataline Surge Protection |
Network/phone line - RJ-11 |
Output Waveform |
Sinewave |
Surge Suppression |
Standard |
Energy Rating |
1920 Joules |
Battery |
Type |
UPS battery |
Technology |
Lead acid |
Run Time (Up To) |
5 min at full load |
Expansion / Connectivity |
Interfaces |
1 x USB - 4 pin USB Type B |
Miscellaneous |
Cables Included |
1 x USB cable
1 x phone cable |
Equipment Protection Value |
200000 US Dollars |
Compliant Standards |
FCC Class B certified, cUL, NOM, UL 1778 |
Manufacturer Warranty |
Service & Support |
2 years warranty |
Service & Support Details |
Limited warranty - 2 years |
