Manufacturer |
Startech Computer Products |
Manufacturer Part Number |
CAB831HD |
Manufacturer Website Address |
www.startech.com |
Product Line |
StarView |
Product Name |
StarView KVM Switch |
Marketing Information |
Manage all your computers from one convenient location with a
StarTech.com KVM switch. Designed for use with our 1UCABCONS or
1UCABCONS17 TFT panel integrated cabinet consoles, this hybrid KVM
allows you to manage 8 USB or PS/2 computers from one console.
The CAB831HD uses an intuitive on-screen display and hot-key
combinations that let you switch between computers quickly and
effectively. Manual and Auto scan modes are provided for easy
monitoring of all your systems.
The CAB831HD switch fits on your server rack, behind your
1UCABCONS or 1UCABONS17 console and uses rear cable connections for
maximum space efficiency. Multiple KVM switches can be cascaded to
support up to 64 computers.
|
Product Type |
KVM Switch |
|
Number of Computers |
8 |
Number of Users |
1 x Local User |
Video Signal |
VGA |
Graphics Resolution |
1920 x 1440 |
Scan Intervals |
3, 8, 15, 30 seconds
|
Security |
Login Password: 4
character/computer
|
Platform Support |
PC
Mac
Linux
|
|
User/Console Ports |
1 x 6-pin mini-DIN (PS/2 Style) Female Keyboard
1 x 6-pin mini-DIN (PS/2 Style) Female Mouse
1 x 15-pin D-Sub (HD-15) Female VGA
|
Computer Ports |
8 x 15-pin D-Sub (HD-15) Female |
Other Ports |
1 x 36-pin Centronics Female |
|
Input Voltage |
9 V DC |
Input Current |
600mA |
|
Form Factor |
1U 19" Rack-mountable |
Dimensions |
1.7" Height x 17.2" Width x 7.0" Depth |
Shipping Dimensions |
2" Height x 6.5" Width x 21" Depth |
Shipping Weight |
5.5 lb Approximate |
|
Additional Information |
Universal 8 port KVM switch Module
controls up to 8 computers directly and up to 64 computers by cascading
8 additional KVM switches
Hot-pluggable feature allow
computers to be added or removed without shutting down
Auto Scan Mode lets you switch
between computers for easy monitoring
Each computer name can be defined
via the OSD menu
Uses StarTech.com tangle-fee KVM
cables
Operating system independent
No software or drivers required
DDC2B compatible
|
System Requirement |
1 x StarTech.com 1UCABCONS or
1UCABCONS17
2-in-1 USB KVM Cable
3-in-1 PS/2 KVM Cable
|
Compatibility |
Supports IntelliMouse (Pro)
Plug and Play
|
Certifications & Standards |
FCC Part 15
|
|
Standard Warranty |
3 Year(s) |
Parts Warranty/Labor |
3 Year(s) |
