Specifications

• Mfr Part Number: 100-W1-0500-KR
• Features:
  • Heavy-duty Protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection) and OTP (Over Temperature Protection)
  • Quiet and Intelligent Auto Fan for near-silent operation
• Maximum Power: 500 W
• Input:
  • Voltage: 100 ~ 240 VAC
  • Current: 8 A
  • Frequency Range: 50 ~ 60 Hz
• Type: ATX12V
• Efficiency: 80% Typical
• Fan: 1x 120mm Fan
• Output: +3.3V @ 24A, +5V @ 20A, +12V @ 40A, +5VSB @ 3A, -12V @ 0.3A
• Connectors: 1x 24Pin ATX Main Power Connector, 1x 8Pin EPS12V Power Connector, 2x 6+2Pin PCI-Express Connectors, 6x SATA Connectors, 3x 4pin Molex Connectors, 1x Floppy Connector
• Approvals: TUV, cUL, UL, CE, FCC, WEEE, RoHS
• Dimensions (WxLxH): 150.0 x 140.0 x 85.0 mm
• Weight: 4.0 lbs
