Specifications

• Mfr Part Number: TL-POE150S
• Features:
  • IEEE 802.3af compliant
  • Delivers power up to 100 meters(328.1 feet)
  • Auto-determine the necessary power requirements
  • Plug-and-Play, requires no configuration
  • External power adapter supply
• Hardware Features:
  • Interface: 2x 10/100/1000Mbps RJ45 Ports (AUTO Negotiation/AUTO MDI/MDIX), 1x 48VDC Power Input Port
  • Network Media:
    • 10BASE-T: UTP category 3, 4, 5 cable (maximum 328.1feet), EIA/TIA-568 100Ω STP (maximum 328.1feet)
    • 100BASE-TX: UTP category 5, 5e cable (maximum 328.1feet), EIA/TIA-568 100Ω STP (maximum 328.1feet)
  • LED Indicator: PWR
  • Power Supply: 15.4W (Max. 48VDC)
  • Dimensions (WxDxH ): 3.2 x 2.1 x 0.9 inch / 80.8 x 54.0 x 24.0 mm
• Software Features:
  • Basic Function: Compatible With IEEE 802.3af Compliant PDs; Delivers Power Up To 100 Meters; Auto-Determine The Necessary Power Requirements
• Others:
  • Certification: FCC, CE, RoHS
  • System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux
  • Environment:
    • Operating Temperature: 0°C~40°C (32°F~104°F)
    • Storage Temperature: -40°C~70°C (-40°F~158°F)
    • Operating Humidity: 10%~90% non-condensing
    • Storage Humidity: 5%~90% non-condensing
